RAP 2.2 Jam Type B
Do the following if the lead edge is stopped past nip N1 to lead edge is
stopped just before nip N5.
1. Check to see if there is any obstruction in the paper path from nip N1
to nip N5 (PL 3.4).
Do RAP 2.8 Checking Obstruction in Paper Path - Area 2 (Entrance
Idler Panel Assembly).
This clears the fault
Yes- Return to normal operation; No- Go to Step 2
2. Check Sensors S1,S2, S3,S4,S5,S18,S19,S20,S21, and S25
• Do RAP 3.1 Check Sensors S1, S2, S3, S4, S5, S22, S23, S24,
S25, S26
and
• Do RAP 3.2 Check Sensors S6 to S21.
This clears the fault
Yes- Return to normal operation; No- Go to Step 3
3. Do RAP 5.1, Checking Stepper Motors to check Motor M1 and
Motor M8.
This clears the fault
Yes- Return to normal operation; No- Go to Step 4
4. Do RAP 4.3 Check Solenoids SOL 3 to SOL 8 to 8 to check solenoids
SOL3 and SOL 4.
This clears the fault
Yes- Return to normal operation; No- Go to Step 5
5. Check the diverter mechanism (PL 3.3, PL 3.8). Do RAP 4.1 Check
Solenoid SOL 1.
This clears the fault
Yes- Return to normal operation; No- Go to Step 6
6. Check the nip force of rollers N2, N3, N4 (PL 3.4). This can be done
by:
• Do GP 6.14 Idler Roller Inspection and Cleaning to inspect the
idler roller springs for these rollers.
• Do GP 6.15 Drive Roller Inspection and Cleaning to check the
Drive Roller condition. Clean if necessary.
• Check the Paper path drive panel positions- see ADJ 1.8, Drive
Panel Position Adjustment and perform adjustments if necessary.
• Check the Entrance Idler Panel position (PL 4.2)- see ADJ 1.7
Idler Panel Magnetic Latches Adjustment, perform adjustment as
necessary.
This clears the fault
Yes- Return to normal operation; No- Escalate to second level
