Close Door
The CLOSE DOOR message indicates that the Front Door is open or not
completely closed.
1. Check that the Front Door is closed (PL 2.2).
The Front Doors is closed.
Y N
Close the Front Door and return to normal operation.
2. Insert an Interlock Cheater into the Punch Door interlock Switch SW4
(PL 2.2).
WARNING
Moving Parts, keep hands clear of nips and the belts when
the Interlock Cheater is inserted. See Section 0, page vii
for other languages.
3. Check if the Close Front Door message is displayed.
The Close Front Door message is displayed.
Y N
Do ADJ 1.1 Door Latch adjustment and return to normal
operation
Go to Step 4.
4. Do REP 1.6 to remove the Rear Cover and check if the Interlock
Cable 023N01332 (see Section 7 Wiring) is connected at J8 at the
Main Control Board (PL 7.1).
Interlock Cable is connected at J8.
Y N
Make the connection and return to normal operation.
5. Switch OFF the machine and unplug the Power Cord.
6. Remove the M4 Nuts (2) that hold the Interlock Switch Bracket (PL
2.2) and inspect the connections at the Interlock Switch (see
REP 1.13 Interlock switch replacement for photos of the connections).
Interlock cable is connected at the Interlock switch.
Y N
Make the connection and return to Normal operation
Go to step 7.
7. Inspect the connection at J17 at the Main Control Board. It is a 16 pin
connector to a 16 pin terminal.
The connection at J17 is good.
Y N
Make the connection and return to normal operation.
8. Do GP 6.2.16 Firmware Upgrade procedure to re-flash the Firmware
for Advanced Punch Pro,
Re-flashing the firmware clears the fault.
Y N
Go to Step 9.
Return to normal operation.
9. Do REP 1.13 Interlock Switch Replacement to replace the Interlock
switch,.
Replacing the switch clears the fault.
Y N
Go to Step 10.
Return to normal operation.
10. Replace Interlock Switch Cable 023N01332 (PL 7.3).
Replacing the cable clears the fault.
Y N
Replace the Main Control Board (PL 7.1).
Return to normal operation.
