GBC AdvancedPunch Pro - Chip Tray Full

GBC AdvancedPunch Pro 11/07/2018 RAPS
2-10
Chip Tray Full
The Chip Tray full message is displayed when the punch chips fill the chip
tray and the capacity is exceeded.
1. Remove the Chip tray and empty the punch chips.
This clears the fault.
Y N
Go to Step 2.
Return to normal operation
2. Clean the Chip Level Emitter and Chip Level Receiver Sensors
(PL 3.5). Ensure the sensor path is clear with the Chip Tray installed.
The Chip Level Emitter and Receiver Sensors are located in the Chip
Tray cavity in the lower portion of the front frame. See REP 2.31 and
2.32 for more details.
This clears the fault
Y N
Go to step 3.
Return to normal operation.
3. Remove the Chip Tray and check if the Chip level Emitter and Chip
level Receiver (PL 3.5) are plugged in.
The Chip level emitter and receiver are located in the Chip tray cavity
in the lower portion of the front frame. See REP 2.31 and REP 2.32
for more details.
See the Sensor Cables table on page 2-35 for cable numbers.
The connections are good.
Y N
Make the connection and return to normal operation.
4. Do REP 1.6 to remove the Rear Cover.
5. Check if Cable 023N01327 (see Section 7 Wiring) is connected to
J27 at the Main Control Board (PL 7.1).
The connection is good.
Y N
Make the connection and return to normal operation.
Go to step 6.
6. Do GP 6.2.16 Firmware Upgrade procedure to re-flash the Firmware
for Advanced Punch Pro,
Re-flashing the firmware clears the fault.
Y N
Go to Step 7.
Return to normal operation.
7. Do REP 2.31 to replace the Chip Level Emitter (PL 3.5).
This clears the fault
Y N
Go to Step 8.
Return to normal operation.
8. Do REP 2.32 to replace the Chip Level Receiver (PL 3.5).
This clears the fault.
Y N
Go to Step 9.
Return to normal operation.
9. Replace cable 023N01327 (PL #)
This clears the fault.
Y N
Do REP 5.1 to replace the Main Control Board (PL 7.1).
Return to normal operation.
