6 OTHER FAULTS
RAP 6.1 Die Set Will Not Slide In or Out Easily
Use this RAP when the Die Set will not slide in or out using a moderate
pull.
1. Do GP 6.27 Die Lock Mechanism and Die Rail Springs Inspection.
This clears the fault
Yes- Return to normal operation; No- Go to Step 2
2. Check if the Punch Cam needs to be indexed. Do ADJ 1.5 Punch
Cam Indexing and perform the adjustment if necessary.
This clears the fault
Yes- Return to normal operation; No- Escalate to second level
RAP 6.2 Punch Overheats
Use this RAP if the Punch Overheats.
1. Check that the Exhaust Fan operates when power is on. Do GP
6.2.12 Function Tests- Fan Test.
The Exhaust Fan operates
Y N
Go to step 2.
To prevent excessive heat build-up, the maximum recommended
monthly punch volume should not exceed 400,000. In addition, no
more than 2 sheets of 300gsm per 5 sheets of 75 gsm.
This clears the fault
Y N
Go to step 2.
Normal operation.
2. Check for obstructions at the vents in the Rear Cover.
This clears the fault.
Y N
Go to step 3.
To prevent excessive heat build-up the maximum recommended
monthly punch volume should not exceed 400,000. In addition, no
more than 2 sheets of 300gsm per 5 sheets of 75 gsm.
3. Check for 24 VDC on Wire 7715267 at the Exhaust Fan.
There is 24 VDC
Y N
Go to step 4 to check input power.
Replace the Exhaust Fan (PL 2.2).
4. Check for 24 VDC on Wire 127N07842 at Connector J20 on the
Control Board (see Section 7 Wiring)
There is 24 VDC
Y N
Do RAP 1.3 No Power to Control Board.
Replace Wire 127N07842 (PL 7.3)
