RAP 1.5 Operator Panel Does Not Show Text
Use this RAP when the LCD Display does not show text but illuminates.
1. Power OFF the print engine and all the connected devices. For DFA
configuration only- Press the Power switch to the OFF position.
2. Wait 20 seconds then power ON the device(s).
The Operator Interface illuminates.
Y N
Go to step 3.
Normal operation.
3. Check that LCD Cable 023M01337 is connected at Connector J36 on
the Control Board (see Section 7 Wiring).
Cable 023M01337 is connected at Connector J36.
Y N
Connect Cable 7715523.
4. Check that LCD Cable 7715523 is connected at the LCD Panel on
the rear of the User Interface (See Section 7 Wiring and PL 2.2).
Cable 023M01337 is connected at the LCD Panel.
Y N
Connect Cable 023M01337
5. Upload firmware: Do GP 6.1.16
The Operator Interface shows text.
Y N
Go to step 6.
Normal operation.
6. Check the condition of LCD Cable 023M01337 (see Section 7 Wiring)
LCD Cable 023M01337 is okay.
Y N
Replace LCD Cable 023M01337 (PL 7.3)
Go to Step 7
7. Replace the LCD Board on the rear of the User Interface (REP 1.15)
This clears the fault
Y N
Go to Step 8
Normal operation.
8. Check LCD for normal operation.
The Operator Interface shows text.
Y N
Replace the Main Control Board (REP 5.1).
Normal operation.
