AdvancedPunch Pro Maintenance Schedule
Note: cycles = sheets of paper punched, not impressions.
Customer Maintenance
Area/Unit
Period
See:
Measures
Remarks
Punch Die
100K Die cycles
GP 6.7.3
Lubrication
Oil the punch pins
Die set shoulder bolts
200k Die cycles
GP 6.7.4
Inspect and lubricate
Grease
Periodic Maintenance
Area/Unit
Period
See:
Measures
Remarks
Punch Drive Cams
5000K cycles
GP 6.20
Inspect and lubricate
Punch Motor Belt
1,000K cycles
GP 6.21
Inspect
Alignment Stepper Belt
1,000K cycles
GP 6.21
Inspect
Steering Carriage Belt
1,000K cycles
GP 6.21
Inspect
Steering Rollers
1,000K cycles
GP 6.14
Inspect and clean
Alcohol and Cloth
Punch Clutch Cleaning
1,000K cycles
GP 6.24
Clean
Cloth
Sensors S1 to S28
500K cycles
GP 6.17
Clean
Air
Drive and Idler Rollers
1,000K cycles
GP 6.14 & GP 6.15
Inspect and clean
Alcohol & cloth
Solenoid Module
1,000K cycles
GP 6.22
Inspect
Idler Panel Closing Magnet
Latches
1,000K cycles
GP 6.16
Inspect
Acceleration Panel Latch
1,000K cycles
GP 6.16
Inspect
Paper Path Drive Timing
Belts
1,000K cycles
GP 6.21
Inspect and Adjust if
necessary
Diverter Solenoid Assembly
1,000K cycles
GP 6.25
Inspect
Die Set Recognition Board
Clips
1,000K cycles
GP 6.26
Clean
Cloth
Alignment Carriage Rails
500K Cycles
GP 6.23
Inspect and Clean
Air and Cloth
Die Lock Mechanism and
Die Rail Springs
1000K Cycles
GP 6.27
Inspect
Die guide (rail) cleaning
500K cycles
GP 6.12
Clean
Vacuum
Paper path
1000K cycles
GP 6.18 & GP 6.19
Inspect and clean
Cloth
