GBC AdvancedPunch Pro Service Manual

Parts List 09-11-2018 GBC AdvancedPunch Pro
5-32
PL 6.3. Cable Part Number Index
Refer to the Wiring drawing on the next page to locate the cables
GBC
Part #
Xerox Part
#
DESCRIPTION
7715451
023N01343
CABLE, SENSORS S1,S25, S26
7715453
023N1346
CABLE, SENSORS, ENTRY
7715459
023N01347
CABLE, SENSORS, EXIT
7715466
023N01351
CABLE, SOLENOIDS, ENTRY, BRD TO HDR
7715467
023N01352
CABLE, SOLENOIDS, EXIT, BRD TO HDR
7715468
023N01333
CABLE, ENTRANCE & ACCEL, DRIVER
7715470
023N01323
CABLE, ALIGN & STEERING DRIVER
7715473
023N01334
CABLE, EXIT, DECEL & BYPASS DRIVER
7715476
023N01340
CABLE, PUNCH MOTOR
7715477
023N01339
CABLE, POWER, STEPPER DRIVERS
7715485
023N01327
CABLE, CHIP TRAY
7715487
023N01332
CABLE, DOOR INTERLOCK
7715490
023N01356
CABLE, USB
7715492
023N01329
CABLE, DC POWER
7715493
023N01322
CABLE, AC TO PSU
7715494
023N01321
CABLE, AC TO BOARD
7715495
023N01331
CABLE, DIE SET RECOGNITION
7715498
023N01336
CABLE, AC FILTER TO AC REMOTE (OEM ONLY)
7715535
023N01335
CABLE, INLET FILTER TO AC SWITCH (DFA ONLY)
7715508
023N01350
CABLE, SKEW, HDR TO SENSOR
7715509
023N01325
CABLE, ALIGN, HDR TO SENSOR
7715510
023N01326
CABLE, BG, HDR TO SENSOR
7715523
023M01337
CABLE, LCD
7715525
023N01320
CABLE, AC FILTER, GROUND
7715548
030N00802
CABLE ASSY, COMMUNICATION
7715528
023N01353
CABLE, STEERING MOTOR, MTR TO HDR, FRONT
7715529
023N01354
CABLE, STEERING, MOTOR, MTR TO HDR, REAR
