GBC AdvancedPunch Pro Service Manual

Repairs/Adjustments 08/20/2015 GBC AdvancedPunch Pro
4-8
REP 1.7 Upstream Rear Side Cover Replacement
PARTS LIST ON PL 2.2
Use this procedure to remove and install the Upstream Rear Side Cover.
Removal Procedure
WARNING
Do not perform repair activities with the power on or electrical power
supplied to the machine. Some machine components contain
dangerous electrical voltages that can result in electrical shock and
possible serious injury. See Section 0, page vi for other languages.
1. Switch power OFF to entire printing system.
2. Disconnect the Power Cord.
3. Do GP 6.4 to undock the Punch from the upstream and downstream
equipment.
4. Do REP 1.6 to remove the Rear Cover.
5. Remove the Screw from the right side of the Exhaust Fan Bracket
Assembly.
6. Remove the Screws (6) holding the Upstream Rear Side Cover.
7. Remove the Upstream Rear Side Cover.
-
Installation Procedure
1. Place the Upstream Rear Side Cover in position.
2. Tighten the Screws (6) holding the Upstream Rear Side Cover.
3. Insert and tighten the Screw at the right side of the Exhaust Fan
Bracket Assembly.
4. Do REP 1.6 to install the Rear Cover.
5. Do GP 6.3 to dock the Punch to the upstream and downstream
equipment.
6. Connect the Power Cord.
7. Power ON the entire printing system.
