GBC AdvancedPunch Pro 09/11/2018 General Procedures and Information
6-25
Service User Interface
The Service User Interface allows you to:
 Set the Paper Size, Max bypass sheet size, Run Mode, Line
speed.
 Check the operation of the Sensors, Solenoids, and the Motors.
 Run the Cycle Punch and Aligner Test routines.
 Set the Skew Offsets, Align offsets
 View Die Cycles.
 Obtain Log file.
 Perform Firmware Upgrade.
When the Service user Interface is open, the top row of text and the
bottom row of text display the options on the Service User Interface
menu.
Paper Size
The Paper Size feature allows you to select the desired paper size.
 ANSI
 ISO
Max Bypass
The Max Bypass feature allows you to set the maximum sheet length that
will be bypassed through AdvancedPunch Pro.
Run Mode
The Run Mode feature allows you to select the desired run mode.
 AUTO RUN
 AUTO CYCLE
Die cycles
The Die cycles menu displays the number of punched cycles on the die
currently installed.
Sensors
The Sensors feature allows you to view the state of each of the 29
sensors to the AdvancedPunch Pro.
 0 means the sensor is open.
 1 means the sensor is covered
Press the Up Arrow button and Down Arrow buttons to scroll through the
list of sensors.
Solenoids
The Solenoid feature allows you to test the operation of each of the 8
solenoids to the AdvancedPunch Pro.
Press the Up Arrow button and Down Arrow buttons to scroll through the
list of solenoids.
