GBC AdvancedPunch Pro 11/07/2018 RAPS
2-25
RAP 2.5 Jam Type E
Do the following if the first jammed sheet’s trail edge is past N6 and N7
1. Check to see if there is any obstruction in the paper path from N8 to
N11.
Do RAP 2.8 Checking Obstruction in Paper Path.
This clears the fault
Yes- Return to normal operation; No- Go to Step 2
2. Do RAP 3.1 to check Sensors S3, S4, S5, S22, S23, S24, and S25.
This clears the fault
Yes- Return to normal operation; No- Go to Step 3
3. Do RAP 3.2 to check Sensors S6, S7, S8, S9, S10, S11, S12, S13,
S14, S15, S16, S17, S18, S19, S20, and S21.
This clears the fault
Yes- Return to normal operation; No- Go to Step 4
4. Do RAP 3.3 to check Sensor S28.
This clears the fault
Yes- Return to normal operation; No- Go to Step 5
5. Do RAP 4.3 to check Solenoids SOL3 to SOL8.
This clears the fault
Yes- Return to normal operation; No- Go to Step 6
6. Do RAP 5.1 to check Motors M6, M7, and M8.
This clears the fault
Yes- Return to normal operation; No- Go to Step 7
7. Check the nip forces of roller N8, N9, and N10. This can be done by:
(same as Jam type B)
• Do GP 6.14 Idler Roller Inspection and Cleaning to inspect the
idler roller springs for these rollers (PL 4.4).
• Do GP 6.15 Drive Roller Inspection and Cleaning to check the
Drive Roller condition. Clean if necessary.
• Check the Paper path drive panel positions - do ADJ 1.8 Drive
Panel Position Adjustment and perform adjustments if necessary.
• Check the Exit Idler Panel position (PL 3.1) - See ADJ 1.7 Idler
Panel Magnetic Latches Adjustment. Perform adjustment if
necessary
This clears the fault
Yes- Return to normal operation; No- Escalate to second level
To Next Page
