RAP 1.2 No DC Power
Use this RAP when there is no indication of 24 VDC power.
1. Do REP 1.6 to remove the Rear Cover.
2. Plug in the AC power cord and turn ON the AC power switch.
WARNING
Moving Parts, keep hands clear of nips and the belts when
the Interlock Cheater is inserted. See Section 0, page vii for
other languages.
3. Check the LEDs on the Control Board.
• With the front door closed there will be (4) LEDs that will be lit.
• With the front door open, there will be (3) LEDs that will be lit.
The LEDs are lit.
Y N
Go to step 4.
Go to step 9.
4. Check for line voltage on Cable 023N01322 (see Section 7 Wiring) at
Connector J3 on the Main Control Board (PL 7.1).
There is line voltage.
Y N
Do RAP 1.1 No AC Power.
5. Check the following connections (see Section 7 Wiring):
• Connection of cable 023N01329 at J1 at the Main Control Board.
• Connection of cable 023N01322 at J3 at the Main Control Board.
Connections are good.
Y N
Make the connections then return to normal operation.
6. Do REP 4.1 to remove 24 VDC Power Supply.
7. With the power supply outside the machine, make the connections at
J1 and J3 and the ground cable.
WARNING
Do not touch the open terminals of the power supply or any other
connector with the AC power cord connected. The machine
components contain dangerous electrical voltages that can result
in electrical shock and possible serious injury. See Section 0,
page viii for other languages
8. Check if the LED in the power supply is lit
LED is lit
Y N
Go to Step 9
Go to Step 10
9. Replace Cable 023N01322 (PL 7.3)
This clears the fault.
Y N
Go to Step 10
Return to normal operation
10. Check if there is no 24V power to any other components like a
Solenoid, or a Stepper Motor,
There is no 24V power to any other components
Y N
Go to Step 11
Replace the Main Control board (PL 7.1)
11. Check for 24 VDC on Cable 023N01329 (see Section 7 Wiring) at
Connector J1 on the Control Board.
• Pin 1 = ORG Wire
• Pin 2 = ORG Wire
• Pin 3 = ORG Wire
• Pin 6 = BLK Wire
• Pin 7 = BLK Wire
• Pin 8 = BLK Wire
There is 24 VDC at Connector J1 on the Control Board
Y N
Replace Cable 023N01322 (PL 7.3)
12. Determine if you have been directed here from another RAP because
there is no 24 VDC power output from the Control Board to another
component.
There is no 24 VDC power output from the Control Board to
another component.
Y N
Normal operation.
Replace the Main Control Board (PL 7.1).
