GBC AdvancedPunch Pro - Chip Tray out; Chip Tray out Message Is Not Displayed When the Chip Tray Is out

GBC AdvancedPunch Pro 11/07/2018 RAPS
2-9
Chip Tray Out
This message is displayed when the Chip tray is removed from the
machine or when the chip tray is not fully inserted.
Use this procedure when the Chip Tray Out message is displayed when
the Chip tray is inserted.
1. Open the Front door and insert the Chip Tray firmly.
This clears the fault.
Y N
Go to Step 2.
Return to normal operation
2. Inspect if the Spring Clip of the Chip tray home switch (PL 3.5, SW2).
If the Spring Clip is broken, do REP 2.30 Chip Tray Home Switch
Replacement.
This clears the fault.
Y N
Go to Step 3.
Return to normal operation
3. Do GP 6.2.16 Firmware Upgrade procedure to re-flash the Firmware
for Advanced Punch Pro,
Re-flashing the firmware clears the fault.
Y N
Go to Step 4.
Return to normal operation.
4. Do REP 2.30, Replace Chip Tray Home Switch,
This clears the fault.
Y N
Go to Step 5
Return to normal operation.
5. Replace Cable 023N01327 (PL 7.3).
This clears the fault.
Y N
Do REP 5.1 Main Control Board Replacement to replace the Main
Control Board (PL 7.1).
Return to normal operation.
Chip Tray Out message is not displayed when the Chip tray is
out
This message is displayed when the Chip Tray Out message is not
displayed when the Chip tray is out.
1. Make sure the (2) spade connectors to the Chip tray home switch (PL
3.5, SW2) is securely inserted. (see REP 2.30 for details)
Connectors are securely connected.
Y N
Securely connect the (2) spade connectors
2. Do REP 1.6 to remove the Rear Cover and check the 023N01327
cable is connected to J27 at the Main Control Board (Section 7
Wiring)
See the Sensor Cables table on page 2-35 for cable numbers.
The connection is good.
Y N
Make the connection and return to normal operation.
3. Do GP 6.2.16 Firmware Upgrade procedure to re-flash the Firmware
for Advanced Punch Pro,
Re-flashing the firmware clears the fault.
Y N
Go to Step 4.
Return to normal operation.
4. Do REP 2.30, Replace Chip Tray Home Switch,
This clears the fault.
Y N
Go to Step 5
Return to normal operation.
5. Replace Cable 023N01327 (PL 7.3).
This clears the fault.
Y N
Do REP 5.1 Main Control Board Replacement to replace the Main
Control Board (PL 7.1).
Return to normal operation.
