GBC AdvancedPunch Pro Service Manual

GBC AdvancedPunch Pro 08/20/2015 Repairs/Adjustments
4-77
Installation Procedure
1. Slide the Diverter Assembly into position through to the rear side.
2. Install the E-clip on the Diverter Shaft at the rear side.
3. Install the M4 screws (2) on the Diverter Shaft at the rear side.
4. Install the E-clip on the Diverter Shaft at the front side.
5. Do REP 1.6 to install the Rear Cover.
6. Connect the Power Cord.
7. Power ON the entire printing system.
8. Do ADJ 1.2 Diverter Solenoid Adjustment.
REP 2.28 Solenoid Replacement
PARTS LIST ON PL 3.8
Use this procedure to remove and install the Solenoids in these
assemblies:
Solenoid
Solenoid #
REP #
Diverter Subassembly
SOL 1
REP 2.28.1
Punch Clutch
SOL 2
REP 3.4
Entrance Idler Solenoid, Middle
SOL 3
REP 2.28.2
Entrance Idler Solenoid, Bottom
SOL 4
REP 2.28.2
Acceleration Roller Idler Solenoid
SOL 5
REP 2.28.3
Exit Idler Solenoid, Bottom
SOL 6
REP 2.28.4
Exit Idler Solenoid, Middle
SOL 7
REP 2.28.4
Exit Idler Solenoid, Top
SOL 8
REP 2.28.4
WARNING
Do not perform repair activities with the power on or electrical power
supplied to the machine. Some machine components contain
dangerous electrical voltages that can result in electrical shock and
possible serious injury. See Section 0, page vi for other languages.
