GBC AdvancedPunch Pro - Sensor Cables

GBC AdvancedPunch Pro 11/07/2018 RAPS
2-35
Sensor
Cables
Sensor Description Cable # Header
Interim
Cable #
Control Board
Connector
S1
Entrance Sensor, S1
023N01343
- - J21 Shares cable with S25, S26
S2
Entrance Sensor, Top
023N1346
- - J22 Shares cable S3, S4, S5
S3
Entrance Sensor, Middle
023N1346
- - J22 Shares cable S2, S4, S5
S4
Entrance Sensor, Bottom
023N1346
- - J22 Shares cable S2, S3, S5
S5
Accel Sensor
023N1346
- - J22 Shares cable S2, S3, S4
S6
Skew Sensor Board
023N01350
Header
023N01349
J23
S7
Skew Sensor Board
023N01350
Header
023N01349
J23
S8
Skew Sensor Board
023N01350
Header
023N01349
J23
S9
Skew Sensor Board
023N01350
Header
023N01349
J23
S10
Skew Sensor Board
023N01350
Header
023N01349
J23
S11
Alignment Sensor Board
023N01325
Header
023N01344
J24
S12
Alignment Sensor Board
023N01325
Header
023N01344
J24
S13
Alignment Sensor Board
023N01325
Header
023N01344
J24
S14
Alignment Sensor Board
023N01325
Header
023N01344
J24
S15
Alignment Sensor Board
023N01325
Header
023N01344
J24
S16
Trail Edge BG Sensor Board
023N01326
Header
023N01345
J25 Shares cable with S28
S17
Trail Edge BG Sensor Board
023N01326
Header
023N01345
J25 Shares cable with S28
S18
Large Mid Punch Sensor Bd
023N01348
- - J26 Shares cable with S20/S21
S19
Large Mid Punch Sensor Bd
023N01348
- - J26 Shares cable with S20/S21
S20
X-Large Mid Punch Sensor Bd
023N01348
- - J26 Shares cable with S18/S19
S21
X-Large Mid Punch Sensor Bd
023N01348
- - J26 Shares cable with S18/S19
S22
Exit Sensor, Bottom
023N01347
- - J28 Shares cable with S23, S24
S23
Exit Sensor, Middle
023N01347
- - J28 Shares cable with S22, S24
S24
Exit Sensor, Top
023N01347
- - J28 Shares cable with S22, S23
S25
Exit Sensor
023N01343
- - J21 Shares cable with S1, S26
S26
Bypass Sensor, Middle
023N01343
- - J21 Shares cable with S1, S25
S27
Bypass Open Sensor
023N01342
- - J30
S28
Align Home Sensor
023N01324
Header
023N01345
J25 Shares cable with S16/S17
S29
Chip Level Sensor -
Emitter/Receiver
023N01327
- - J27
S1B
Clear Cover Sensor –
Emitter/Receiver
023N01355
- - J29
