GBC AdvancedPunch Pro 11/07/2018 RAPS
2-34
2. Make sure the sensor wire is connected securely at the Sensor and at
the Main Control Board (PL 7.1). Do REP 1.6 to remove the Rear
Cover to gain access to the connector at the Control Board.
See the Sensor Cables table in Section 7 Wiring
See REP 2.25 for details on connection at the sensor(s)
All the connections are made securely
Yes- Go to Step 3
No- Make the connection and return to normal operation.
3. Replace the Sensor with a new one (alternatively, swap the sensor in
the faulty position with a sensor from a different good position to
check if it is a bad sensor). See REP 2.25 for Sensor replacement.
• Do GP 6.3 to Undock the AdvancedPunch Pro
• Do REP 1.8 to remove the Upstream Side Frame Cover or do
REP 1.11 to remove the Downstream Side Frame Cover
Replacing the sensor corrects the issue
Yes- Use the new sensor and return to normal operation
No- Go to Step 4
4. Do GP 6.3 to Undock the AdvancedPunch Pro and visually inspect
the Cable from the sensor all the way to the Control Board (PL 7.1). If
the Cable is damaged, replace the Cable.
See the Sensor Cables table in Section 7 Wiring
Sensor cable looks okay
Yes- Go to Step 5
No- Go to Step 6
5. Do GP 6.2.16 FIRMWARE UPGRADE Procedure to Re-flash the
firmware for the AdvancedPunch Pro.
Re-flashing firmware clears the fault
Yes- Resume normal operation; No- Go to Step 6
6. Replace the Sensor Cable.
• Do GP 6.4 to Undock the AdvancedPunch Pro.
• Remove the faulty cable from the sensor by releasing the
required cable clamps.
• Replace with a new cable.
See the Sensor Cables table in Section 7 Wiring
Replacing the sensor cable corrects the issue
Yes- Resume normal operation; No- Go to Step 7
7. Do REP 5.1 to replace the Main Control Board (PL 7.1).
This clears the fault
Yes- Resume normal operation; No- Escalate to second level
