RAP 2.9 PAPER JAM J431
Important Note: Double Punch is available only for DFA configurations.
When Double Punch is selected from the AdvancedPunch Pro LCD, and
a sheet that cannot be “Double punched” is processed through the printer,
AdvancedPunch Pro will stop and display message J431.
RAP 2.10 PAPER JAM J432
Use this RAP if the machine stops and PAPER JAM J432 message is
shown on the LCD.
AdvancedPunch Pro can process sheets that are fed +/- 10mm from the
center. If the sheets are offset more than a specified distance from the
center, Alignment Fail Safe Stop will be reached. To troubleshoot this
condition, do the following:
1. For DFA configurations only- Check if the line speed is set correctly
GP 6.2.2
For all OEM configurations, go to Step 2
Line speed is set correctly
Yes- Go to Step 2; No- correct it and resume normal operation
2. Do RAP 3.1, Check Sensors S1, S2, S3, S4, S5, S22, S23, S24, S25,
S26 to check Sensor S1, S11, S12, S13, S14 and S15
This clear the fault
Yes- Resume normal operation; No- Go to Step 3
3. Check if the Upstream docking bracket is centered. See Section 8.6.1
Upstream docking bracket is installed correctly
Yes- Go to Step 4; No- Install correct and resume normal operation
4. Check the DIP switch settings for Motor Driver DRV M5.
See REP 2.26, Motor Driver (Stepper Board) Replacement for details.
DIP switch for DRV M5 is set correctly
Yes- Escalate to second level;
No- Correct the DIP switch and resume normal operation.
