GBC AdvancedPunch Pro - Gp 6.2.6 die Cycles

GBC AdvancedPunch Pro 09/11/2018 General Procedures and Information
6-35
GP 6.2.6 DIE CYCLES
Do the following to view the number of cycles the die set that is currently
installed in the machine.
1. At the top level screen,
READY
SINGLE PUNCH
Press and hold the both Up Arrow button and the Down Arrow button
for 5 seconds.
Then while still holding down the Up Arrow button and the Down
Arrow button, press the Enter button.
The Service User Interface screen will appear.
SPEED ADJUST
*
PAPER SIZE
2. Press the down arrow so the return symbol is next to DIE CYCLES
and then press OK.
RUN MODE
*
DIE CYCLES
DIE CYCLES
*
501, 175
3. Press OK to return to the service menu. Press up or down arrow and
exit to the Main screen.
