1 POWER FAULTS
RAP 1.1 No AC Power
Use this RAP when there is no AC power to the AdvancedPunch Pro. The
Operator Panel does not illuminate and the AdvancedPunch Pro does not
operate.
1. Ensure the Power is ON for the print engine. For DFA configuration-
Press the Main Power Switch to the On (I) position.
Main Power Switch is in the On (I) position
Y N
Place the Main Power Switch in the On (I) position.
2. Check that the Power Cord is attached to the AC Filter on the rear of
the machine.
Power Cord is attached to AC Filter.
Y N
Attach the Power Cord.
3. Check that the Power Cord is properly plugged into the wall.
Power Cord is plugged into the wall.
Y N
Plug in the Power Cord.
4. Disconnect the Power Cord from the power source and check for
input voltage - 110 VAC (60 Hz) or 240 VAC (50 Hz) - at the power
receptacle.
AC power is present at the recepticle.
Y N
If there is no power at the outlet, ask the customer to call an
electrician to restore the AC power.
5. Reconnect the power cord to the AdvancedPunch Pro.
6. Do REP 1.6 to remove the Rear Cover.
7. Check that Ground Wire 023N01320 (Section 7 Wiring) is connected
to the ground and to the AC Filter.
Ground Wire 023N01320 is connected.
Y N
Connect Ground Wire 023N01320.
Go to step 8.
8. Check that Cable 023N01336 (see Section 7 Wiring) is connected at
the AC Filter. For DFA configurations cable# is 023N01335
Cable 023N01336 (023N01335 for DFA) is connected at AC Filter
Y N
Connect Cable 023N01336 (023N01335 for DFA).
9. For DFA configuration only- Check that Cable 023N01335 (see
Section 7 Wiring) is connected to the Power Switch SW1. For OEM
configurations- go to Step 10.
Cable 023N01335 is connected to the Power Switch.
Y N
Connect Cable 023N01335 to the Power Switch SW1.
10. Check the Fuse on the Communications Board. (Section 7 Wiring)
Fuse is okay
Y N
Replace the Fuse (PL 7.1).
11. Check that Cable 023N01336 (see Section 7 Wiring) is connected to
Pin J14 on the Communications Board. For DFA configurations
cable# is 023N01335
Cable 023N01336 (023N01335 for DFA) is connected to Pin J14.
Y N
Connect Cable 023N01336 (023N01335 for DFA) to Pin J14 on
the Communications Board.
12. Check that Cable 023N01321 (see Section 7 Wiring) is connected to
Pin J15 on the Communications Board.
Cable 023N01321 is connected to Pin J15 on the
Communications Board.
Y N
Connect Cable 023N01321 to Pin J15 on the Communications
Board.
13. Check that Cable 023N01321 (see Section 7 Wiring) is connected to
Pin J4 on the Main Control Board.
