GBC AdvancedPunch Pro Service Manual

Punch Quality 11/07/2018 GBC AdvancedPunch Pro
3-12
Punch Capacity
Single Sheet
Electrical
Amps and
Frequency
115V: 3.8 A; 60 Hz
230V: 1.9 A; 50 Hz
Safety
cULus / GS
Dimensions
L: 730mm; W: 445mm; H: 990mm
Weight
97 kg
Sheet Entrance and Exit Specifications
Curl variance at entrance
±12.7mm
Alignment variance at pick
up
±8.0mm from Center justified
Speed variance at pick up
±2%
Skew variance at pick up
±25mrads
Alignment variance at exit
±2.0mm from Center justified
Skew variance at exit
±5mrads for Punch job
(incremental to skew at entrance
for bypass job)
Speed variance at exit
±1% compared to speed
variance at pick up
Duty Cycles
Maximum recommended
monthly volume
400,000 Punch cycles
Maximum Punch duty cycle
In addition to above, no more
than 2 sheets of 300gsm per 5
sheets of 75gsm
Punch Accuracy
Hole Size
±2%
Alignment position
±0.5mm (with 1% ±0.5 to
±1.0mm)
Backgage Depth (at center)
±0.3mm (with 1% ±0.3 to
±0.8mm)
Skew
±0.6mm (with 1% ±0.6 to
±1.0mm)
