GBC AdvancedPunch Pro 08/20/2015 Repairs/Adjustments
4-25
Installation Procedure
1. Place the Lower Entrance Panel in position.
2. Tighten the Screws (4) used to mount the Lower Entrance Panel
3. Intall the Timing belt pulley shield with (1) screw and (1) nut.
4. Close the Upper Bypass Assembly.
5. Do REP 1.6 Rear Cover Replacement to install the Rear Cover.
6. Do GP 6.3 to dock the Punch to the upstream and downstream
equipment.
7. Connect the Power Cord.
8. Power ON the entire printing system.
9. Do ADJ 1.2 Diverter Solenoid Adjustment.
