GBC AdvancedPunch Pro 08/20/2015 Repairs/Adjustments
4-41
Installation Procedure
1. Transfer the Idler rollers, springs, sensors, Bypass Open sensor flag,
Magnetic latches to the new part.
2. Place the Upper Bypass Assembly.in position.
3. Install the the Handle Assembly.
4. Install the (2) Idler panel magnetic latches.
5. Install the Idler Panel Mount Brackets (2) on the rear frame.
6. Place the Shaft in position and install the (2) E-clips.
7. Connect the Sensors from the Upper Bypass Panel and place the
sensor cables in the cable clamps.
8. Do REP 1.6 Rear Cover Replacement to install the Rear Cover.
9. Do GP 6.3 to dock the Punch to the upstream and downstream
equipment.
10. Connect the Power Cord.
11. Power ON the entire printing system.
12. Do ADJ 1.7 Idler Panel Magnetic Latches adjustment.
