GBC AdvancedPunch Pro 08/20/2015 Repairs/Adjustments

4-101

Installation Procedure

1. Place the new Motor in positions and tighten the Screws (4).

2. Do ADJ 1.4 to set the belt tension.

3. Connect the Steering Motor Cable at the Motor and at the Header.

4. Install the Screws (4) and tighten with the Belt in place.

5. Install the Align Home Sensor Bracket and tighten the M3 Screws (2).

6. Do REP 3.6 to install the Steering Module.

7. Do REP 3.1 to install the Punch Module.

8. Do REP 1.6 to install the Rear Cover.

9. Close the Front Door.

10. Connect the Power Cord.

11. Power ON the entire printing system.
