GBC AdvancedPunch Pro Service Manual

GBC AdvancedPunch Pro 09-11-2018 Parts List
5-39
7715380
F
009N01702
F
SPRING,TRANSPORT IDLR ROLLER
5.15
5.16
5.17
5.18
7715382
013N13947
BEARING HOUSING ASSY
5.15
5.16
5.17
5.17
5.18
7715384
003N01111
HANDLE ASSY, IDLER PANELS
5.15
5.17
5.18
7715625
E
072N00038
E
WIRE SADDLE, SHORT
5.15
5.17
7715629
B
026N00813
B
SCREW, BARREL, M4, 7MM DEEP
5.15
5.16
5.17
5.18
7715639
E
072N00041
E
WIRE SADDLE,SMALL,SIDE OPEN
5.15
5.17
7715853
002N03198
PANEL WLDMT,IDLER,ENTRY
5.15
7715855
002N03197
PANEL WLDMNT,IDLER,ACCEL
5.16
7715202
023N01316
BELT, 534T, 2MM 2GT
5.13
7715204
020N00937
PULLEY,TIMING,2MM 2GT,30T
5.13
7715206
023N01315
BELT, 179T, 2MM 2GT
5.13
7715243
023N01314
BELT, 150 T, 2MM 2GT
5.13
7715245
030N00806
TENSIONER ASSEMBLY
5.13
7715246
023E01313
BELT, 134T, 2MM 2GT
5.13
7715854
002N03199
PANEL WLDMNT,IDLER,EXIT
5.17
7715852
002N03193
PANEL WELDMENT, BYPASS, UPPER
5.18
7715410
180N00019
PUNCH MODULE, ASSY, 115V
5.20
7715409
180N00020
PUNCH MODULE, ASSY, 230V
5.20
1821802
C
028N00371
C
Spring washer M4
5.20
1821532
B
026N00839
B
SCREW, SHCS, M4 X 12
5.20
7715430
002N03219
STEERING MODULE SUB ASSY
5.20
7715368
003N01111
HANDLE, DIE LOCK
5.20
7715856
180N00018
PUNCH MODULE SHELL, SERVICE
5.20
7715859
127K07846
STEPPER MOTOR AND PULLEY,
ALIGNMENT
5.20
5.22
1821541
B
026N00832
B
SCREW, SOCKET HD,M6,35MM LONG
5.21
1821655
B
026N00827
B
SCREW, PHILLIPS, PAN HD, M4X25
5.21
7715232
023N01319
BELT, TIMING, 82 GROOVE, 5MM HTD
5.21
7715372
023N01318
BELT, TIMING, 80 GROOVE, 5MM HTD
5.21
7715238
030N00808
BRACKET & BEARING ASSY, DIE LOCK
5.21
7715239
010N01188
PLUNGER & STRIPPER,DIE LOCK
5.21
7715374
F
009N01697
F
SPRING, DIE LOCK RETURN
5.21
7715347
130N01769
BOARD, DIESET RECOGNITION READER
5.21
7715857
127N07847
Left / Front Steering Motor and Pulley.
5.22
7715857
127N07847
Right / Rear Steering Motor and Pulley.
5.22
7715858
041N00843
ALIGNMENT CARRIAGE,SUB ASSY,
SERVICE
5.23
7706488
013N13950
BEARING, DOUBLE "D" FLANGE
5.24
7715062
002N03200
PANEL WLDMENT,IDLER,STEERING
5.24
7715379
F
009N01701
F
SPRING, STEERING IDLER ROLLER
5.24
7715648
E
072N00034
E
WIRE CLAMP, LOCKING
5.24
7715816
002N02807
ROLLER ASSY, IDLER, STEERING
5.24
1822008
C
028N00376
C
WASHER, FLAT, 6.4X12X1.5
5.25
7715039
022N02804
ROLLER ASSEMBLY, DRIVE, STEERING
5.25
7715047
023N01317
BELT,STEERING,65 GROOVES,2MM 2GT
5.25
7715053
002N03196
PANEL WELDMENT, DRIVE, STEERING
5.25
7715377
F
009N01700
F
SPRING, STEERING DRIVE ROLLER
5.25
7715648
E
072N00034
E
WIRE CLAMP, LOCKING
5.25
7715857
127N07847
STEPPER MOTOR AND
PULLEY,STEERING, SERVICE
5.25
1821531
B
026N00830
B
SCREW, SHCS, M5X18
5.26
A
7715973
600N03432
KIT, HARDWARE, RINGS
B
7715974
600N03433
KIT, HARDWARE, FASTENERS
C
7715975
600N03434
KIT, HARDWARE, WASHERS
D
7715976
600N03435
KIT, HARDWARE, BEARINGS
E
7715977
600N03436
KIT, HARDWARE, WIRE CLAMPS
F
7715978
600N03437
KIT, HARDWARE, SPRINGS
