GBC AdvancedPunch Pro 11/07/2018 RAPS
2-37
Sensors S11, S12, S13, S14 and S15
To Access Sensors S11, S12, S13, S14 and S15
• Undock AdvancedPunch Pro- This step is optional- if possible reach in through the jam access opening without undocking the punch.
• Locate the Alignment Sensor Board
Sensors S11, 12, 13, 14 and 15 are on the Alignment Sensor Board
S15
S14
S13
S12
S11
