GBC AdvancedPunch Pro - Page 65

GBC AdvancedPunch Pro 11/07/2018 RAPS
2-39
Sensors S18, S19, S20 and S21
To Access Sensors S18, S19, S20 and S21:
• Open the Front Door.
• Unlatch and open the Entrance Idler Panel.
Sensors S18 and S19 are on Mid Punch Large Backgage Sensor Board.
Sensors S20 and S21 are on Mid Punch XL Backgage Sensor Board.
