Keysight x-series Programmer's Reference

3 VMA Mode
3.7 Power Stat CCDF Measurement
Freq Option CF after Mode
Preset
Stop Freq after Mode
Preset
Max Freq
(can't tune
above)
F26 (CXA-m) 13.255 GHz 26.5GHz 26.55 GHz
504 (M9421A, M8920A) 2.145 GHz 3.88GHz 3.88 GHz
506 (M9421A, M8920A) 3.245 GHz 6.08GHz 6.08 GHz
F06 (M9410A/11A) 1.0 GHz
6.08 GHz 6.08 GHz
F06 (M9415A)
1 GHz 1.08 GHz
6.6 GHz
F08 (M9415A)
1 GHz 1.08 GHz
8.6 GHz
F12 (M9415A)
1 GHz 1.08 GHz
12.9 GHz
*For option 526, the Max CF in RTSA is 26.999999995 GHz.
N9041B Center Freq Presets
Input CF after Mode Preset Stop Freq after Mode Preset Max Freq
(can't tune above)
Input 1, all models 25.005 GHz 50.0 GHz 52 GHz
Input 2, opt 585 42.505 GHz 85.0 GHz 86 GHz
Input 2, opt 590 45.005 GHz 90.0 GHz 92 GHz
Input 2, opt 5CX 55.005 GHz 110.0 GHz 110 GHz
Input 2, CXA and MXE
Model CF after Mode Preset Stop Freq after Mode Preset Max Freq
(can't tune above)
CXA opt C75 0.7505 GHz 1.5 GHz 1.58 GHz
MXE 505 MHz 1GHz 1.000025 GHz
Tracking Generator Frequency Limits (CXA only)
Tracking
Generator
Option
Min Freq
(clips to this freq when turn
TG on and can’t tune below
while TG on)
If above this Freq, Stop Freq
clipped to this Freq when TG
turned on
Max Freq
(can't tune
above)
while TG on
T03 9 kHz 3.0 GHz 3.08 GHz
T06 9 kHz 6.0GHz 6.05 GHz
Tracking Generator Frequency Limits(CXA-m only)
1131 Vector Modulation Analyzer Mode User's &Programmer's Reference
