3 VMA Mode
3.7 Power Stat CCDF Measurement
Tracking
Generator
Option
Min Freq
(clips to this freq when turn
TG on and can’t tune below
while TG on)
If above this Freq, Stop Freq
clipped to this Freq when TG
turned on
Max Freq
(can't tune
above)
while TG on
T03 2 MHz 3.08 GHz 3.08 GHz
T07 2 MHz 7.575 GHz 7.575 GHz
T13 2 MHz 13.8 GHz 13.8 GHz
T26 2 MHz 26.55 GHz 26.55 GHz
VXT Models with Radio Heads/CIU Frequency Range
The following table shows the Center Frequency Presets and Range for VXT modes
with Radio Heads/CIU.
Products with Radio Heads/CIU Preset Start frequency Stop frequency
M9421A + CIU 6 GHz 5.9 GHz 12 GHz
M9410A + CIU 6 GHz 5.9 GHz 12 GHz
M9410A + CIU + RRH 25 GHz 24.25 GHz 43.5 GHz
RF Center Freq
Lets you specify the RF Center Frequency. Sets the Center Frequency to use when
the RF input is selected, even if the RF input is not selected at the time the
command is sent. Note that Center Frequency in the Frequency menu on the front
panel always applies to the currently selected input.
Remote Command
[:SENSe]:FREQuency:RF:CENTer <freq>
[:SENSe]:FREQuency:RF:CENTer?
Example
:FREQ:RF:CENT 30 MHz
:FREQ:RF:CENT?
Notes This command is the same in all Modes, but the parameter is Measurement Global, so the value is
independent in each mode and common across all the measurements in the mode
Dependencies If the electronic/soft attenuator is enabled, any attempt to set Center Frequency such that the Stop
Frequency would be > 3.6 GHz fails and results in an advisory message
If the equivalent SCPI command is sent, this same message is generated as part of a “-221, Settings
conflict” warning
Preset See "Center Frequency Presets" on page 1130
State Saved Saved in instrument state
Min -79.999995 MHz
Max See "Center Frequency Presets" on page 1130. Basically, instrument maximum frequency - 5 Hz
Vector Modulation Analyzer Mode User's &Programmer's Reference 1132
