3 VMA Mode
3.1 Digital Demod Measurement
3/5, DVB-S2X 16 APSK with code rate 13/18, DVB-S2X 16 APSK with code rate
18/30 (3/5-L), DVB-S2X 16 APSK with code rate 20/30 (2/3-L), DVB-S2X 16
APSK with code rate 23/36, DVB-S2X 16 APSK with code rate 25/36, DVB-S2X 16
APSK with code rate 26/45, DVB-S2X 16 APSK with code rate 28/45, DVB-S2X 16
APSK with code rate 90/180 (1/2), DVB-S2X 16 APSK with code rate 96/180
(8/15), DVB-S2X 16 APSK with code rate 100/180 (5/9), DVB-S2X 16 APSK with
code rate 140/180 (7/9), DVB-S2X 16 APSK with code rate 154/180 (77/90),
DVB-S2X 16 APSK with Short FEC and code rate 3/5, DVB-S2X 16 APSK with
Short FEC and code rate 7/15, DVB-S2X 16 APSK with Short FEC and code rate
8/15, DVB-S2X 16 APSK with Short FEC and code rate 26/45, DVB-S2X 16 APSK
with Short FEC and code rate 32/45, DVB-S2X 32 APSK with code rate 128/180
(32/45), DVB-S2X 32 APSK with code rate 132/180 (11/15), DVB-S2X 32 APSK
with code rate 140/180 (7/9), DVB-S2X 32 APSK with code rate 2/3, DVB-S2X 32
APSK with short FEC and code rate 2/3, DVB-S2X 32 APSK with short FEC and
code rate 32/45, DVB-S2X 64 APSK with code rate 4/5, DVB-S2X 64 APSK with
code rate 5/6, DVB-S2X 64 APSK with code rate 7/9, DVB-S2X 64 APSK with
code rate 128/180 (32/45), DVB-S2X 64 APSK with code rate 132/180 (11/15),
DVB-S2X 128 APSK with code rate 135/180 (3/4), DVB-S2X 128 APSK with code
rate 140/180 (7/9), DVB-S2X 256 APSK with code rate 116/180 (29/45), DVB-
S2X 256 APSK with code rate 124/180 (31/45), DVB-S2X 256 APSK with code
rate 128/180 (32/45), DVB-S2X 256 APSK with code rate 135/180 (3/4), DVB-
S2X 256 APSK with code rate 20/30 (2/3), DVB-S2X 256 APSK with code rate
22/30 (11/15)
Not that xxx-L= MODCODs optimized for quasi-linear channels
Radio APCO 25 C4FM/CQPSK Combined, APCO 25 CQPSK EVM, APCO 25 HCPM, APCO
25 HDQPSK, APCO 25 HDQPSK EVM, TETRA, DMR, dPMR
Other None, DECT, VDL Mode 2/3, MIL-STD CPM (188-181C Opt21), SOQPSK-TG,
SOQPSK-A, SOQPSK-B
Remote
Command
[:SENSe]:RADio:STANdard:PRESet NONE | EDGE | NADC | PDC | PHS | DTV8 | DTV16
| DVB16 | DVB32 | DVB64 | DVB128 | DVB256 | AP1C4FM | AP1CQPSK | AP2HCPM |
AP2HDQPSK | AP2HDQPSKEVM | DMR | DPMR | DECT | TETRA | VDL2 | MILSTDCPM |
WS2F50K1 | WS2F100K1 | WS2F100K05 | WS2F150K05 | WS2F200K1 | WS2F200K05 |
WS2F300K05 | SOQPSKTG | SOQPSKA | SOQPSKB | S2QPSK | S28PSK | DVB16APSK23 |
DVB16APSK34 | DVB16APSK45 | DVB16APSK56 | DVB16APSK89 | DVB16APSK910 |
DVB32APSK34 | DVB32APSK45 | DVB32APSK56 | DVB32APSK89 | DVB32APSK910 |
S2X8CR59 | S2X8CR2645 | S2X16CR35 | S2X16CR1318 | S2X16CR35L | S2X16CR23L |
S2X16CR2336 | S2X16CR2536 | S2X16CR2645 | S2X16CR2845 | S2X16CR12 |
S2X16CR815 | S2X16CR59 | S2X16CR79 | S2X16CR7790 | S2X16CR35S | S2X16CR715S
| S2X16CR815S | S2X16CR2645S | S2X16CR3245S | S2X32CR3245 | S2X32CR1115 |
S2X32CR79 | S2X32CR23 | S2X32CR23S | S2X32CR3245S | S2X64CR45 | S2X64CR56 |
S2X64CR79 | S2X64CR3245 | S2X64CR1115 | S2X128CR34 | S2X128CR79 |
S2X256CR2945 | S2X256CR3145 | S2X256CR3245 | S2X256CR34 | S2X256CR23 |
S2X256CR1115 | WSOQPSKHS | WSOQPSKRC | WL11AYC1M12 | WL11AYC2M12 |
WL11AYC3M12 | WL11AYC4M12 | WP153D
Example
:RAD:STAN:PRES NONE
Notes DVB64APSK45 is an alias for S2X64CR45
307 Vector Modulation Analyzer Mode User's &Programmer's Reference
