Keysight x-series Programmer's Reference

3 VMA Mode
3.1 Digital Demod Measurement
Range
NONE | EDGE | NADC | PDC | PHS(PHP) | ATSC 8VSB | ATSC 16VSB | DVB 16QAM |
DVB 32QAM | DVB 64QAM | DVB 128QAM | DVB 256QAM | APCO25 C4FM/CQPSK Combined
| APCO25 CQPSK EVM | APCO25 HCPM | APCO25 HDQPSK | APCO25 HDQPSK EVM | DMR |
DPMR | DECT | TETRA | VDL Mode2/3 | MI-STD CPM | WiSUN 2FSK 50/1 | WiSUN
2FSK 100/1 | WiSUN 2FSK 100/0.5 | WiSUN 2FSK 150/0.5 | WiSUN 2FSK 200/1 |
WiSUN 2FSK 200/0.5 | WiSUN 2FSK 300/0.5 | SOQPSK-TG | SOQPSK-A | SOQPSK-B |
DVB-S2 QPSK | DVB-S2 8PSK | DVB-S2 16APSK Code Rate 2/3 | DVB-S2 16APSK Code
Rate 3/4 | DVB-S2 16APSK Code Rate 4/5 | DVB-S2 16APSK Code Rate 5/6 | DVB-
S2 16APSK Code Rate 8/9 | DVB-S2 16APSK Code Rate 9/10 | DVB-S2 32APSK Code
Rate 3/4 | DVB-S2 32APSK Code Rate 4/5 | DVB-S2 32APSK Code Rate 5/6 | DVB-
S2 32APSK Code Rate 8/9 | DVB-S2 32APSK Code Rate 9/10 | DVB-S2X 8APSK Code
Rate 5/9 | DVB-S2X 8APSK Code Rate 26/45 | DVB-S2X 16APSK Code Rate 3/5 |
DVB-S2X 16APSK Code Rate 13/18 | DVB-S2X 16APSK Code Rate 3/5-L | DVB-S2X
16APSK Code Rate 2/3-L | DVB-S2X 16APSK Code Rate 23/36 | DVB-S2X 16APSK
Code Rate 25/36 | DVB-S2X 16APSK Code Rate 26/45 | DVB-S2X 16APSK Code Rate
28/45 | DVB-S2X 16APSK Code Rate 1/2 | DVB-S2X 16APSK Code Rate 8/15 | DVB-
S2X 16APSK Code Rate 5/9 | DVB-S2X 16APSK Code Rate 7/9 | DVB-S2X 16APSK
Code Rate 77/90 | DVB-S2X 16APSK Code Rate 3/5 Short FEC | DVB-S2X 16APSK
Code Rate 7/15 Short FEC | DVB-S2X 16APSK Code Rate 8/15 Short FEC | DVB-S2X
16APSK Code Rate 26/45 Short FEC | DVB-S2X 16APSK Code Rate 32/45 Short FEC
| DVB-S2X 32APSK Code Rate 32/45 | DVB-S2X 32APSK Code Rate 11/15 | DVB-S2X
32APSK Code Rate 7/9 | DVB-S2X 32APSK Code Rate 2/3 | DVB-S2X 32APSK Code
Rate 2/3 Short FEC | DVB-S2X 32APSK Code Rate 32/45 Short FEC | DVB-S2X
64APSK Code Rate 4/5 | DVB-S2X 64APSK Code Rate 5/6 | DVB-S2X 64APSK Code
Rate 7/9 | DVB-S2X 64APSK Code Rate 32/45 | DVB-S2X 64APSK Code Rate 11/15 |
DVB-S2X 128APSK Code Rate 3/4 | DVB-S2X 128APSK Code Rate 7/9 | DVB-S2X
256APSK Code Rate 29/45 | DVB-S2X 256APSK Code Rate 31/45 | DVB-S2X 256APSK
Code Rate 32/45 | DVB-S2X 256APSK Code Rate 3/4 | DVB-S2X 256APSK Code Rate
2/3 | DVB-S2X 256APSK Code Rate 11/15 | WiSUN OQPSK Half Sine | WiSUN OQPSK
Raise Cosin | 802.11ay CB1 MCS12 | 802.11ay CB2 MCS12 | 802.11ay CB3 MCS12 |
802.11ay CB4 MCS12 | 802.15.3d
Backwards
Compatibility
SCPI
[:SENSe]:RADio:STANdard:PRESet NONE | EDGE | NADC | PDC | PHS | DTV8 | DTV16
| DVB16 | DVB32 | DVB64 | DVB128 | DVB256 | AP1C4FM | AP1CQPSK | AP2HCPM |
AP2HDQPSK | AP2HDQPSKEVM | DMR | DPMR | DECT | TETRA | VDL2 | MILSTDCPM |
WS2F50K1 | WS2F100K1 | WS2F100K05 | WS2F150K05 | WS2F200K1 | WS2F200K05 |
WS2F300K05 | SOQPSKTG | DVB16APSK23 | DVB16APSK34 | DVB16APSK45 |
DVB16APSK56 | DVB16APSK89 | DVB16APSK910 | DVB32APSK34 | DVB32APSK45 |
DVB32APSK56 | DVB32APSK89 | DVB32APSK910 | DVB64APSK45 | S2X64CR56 |
S2X64CR79 | S2X64CR3245 | S2X64CR1115 | S2X128CR34 | S2X128CR79 |
S2X256CR2945 | S2X256CR3145 | S2X256CR3245 | S2X256CR34 | S2X256CR23 |
S2X256CR1115
The following tables list the standard presets supported by the VMA:
Preset To Standard – Cellular
Parameter NADC EDGE PDC PHP (PHS)
Modulation Format pi/4 DQPSK EDGE (3p/8 8PSK) pi/4 DQPSK pi/4 DQPSK
Info BW 75 kHz 625 kHz 75 kHz 625 kHz
Symbol Rate 24.3 kHz 270.83 kHz 21 kHz 192 kHz
Meas Filter Root Raised Cosine EDGE Root Raised Cosine Root Raised Cosine
Vector Modulation Analyzer Mode User's &Programmer's Reference 308
