3 VMA Mode
3.1 Digital Demod Measurement
Parameter NADC EDGE PDC PHP (PHS)
Ref Filter Raised Cosine EDGE Raised Cosine Raised Cosine
Filter Alpha 0.35 0.5 0.5
Points / Symbol 5 1 5 5
Meas Interval 157 symbols 142 symbols 135 symbols 111 symbols
Search Length ~48.4 ms ~5.29 ms ~47.6 ms ~5.73 ms
Burst Search On On On On
Sync Search Off Off Off Off
Preset To Standard – Wireless
Parameter Wi-SUN
2-FSK 50/1
Wi-SUN
2-FSK 100/1
Wi-SUN
2-FSK 100/0.5
Wi-SUN
2-FSK 150/0.5
Modulation Format 2-FSK 2-FSK 2-FSK 2-FSK
Info BW 200 kHz 400 kHz 400 kHz 600 kHz
Symbol Rate 50 kHz 100 kHz 100 kHz 150 kHz
Meas Filter None None None None
Ref Filter Gaussian Gaussian Gaussian Gaussian
Filter BT 0.5 0.5 0.5 0.5
Points / Symbol 20 20 20 20
Meas Interval 2875 symbols 2875 symbols 2875 symbols 2875 symbols
Search Length
Burst Search Off Off Off Off
Sync Search Off Off Off Off
FSK Deviation Reference (Manual) 25 kHz 50 kHz 25 kHz 37.5 kHz
Parameter Wi-SUN
2-FSK 200/1
Wi-SUN
2-FSK 200/0.5
Wi-SUN
2-FSK 300/0.5
Wi-SUN
OQPSK Half Sine
Modulation Format 2-FSK 2-FSK 2-FSK OQPSK
Info BW 800 kHz 800 kHz 1.2 MHz 5 MHz
Symbol Rate 200 kHz 200 kHz 300 kHz 1 MHz
Meas Filter None None None None
Ref Filter Gaussian Gaussian Gaussian Half Sine
Filter BT 0.5 0.5 0.5 NA
Points / Symbol 20 20 20 10
Meas Interval 2875 symbols 2875 symbols 2875 symbols 501 symbols
Search Length 610 usec
Burst Search Off Off Off Off
Sync Search Off Off Off Off
309 Vector Modulation Analyzer Mode User's &Programmer's Reference
