Planet SGS-6341-24T4X User Manual

52-2
online time for port the authenticated user is using. The switch will send an “accounting started”
message to the RADIUS accounting server on starting the accounting, and an accounting packet for
the online user to the RADIUS accounting server every five seconds, and an “accounting stopped”
message is sent to the RADIUS accounting server on accounting end. Note: The switch send the
“user offline” message to the RADIUS accounting server only when accounting is enabled, the “user
offline” message will not be sent to the RADIUS authentication server.
Example:
Enabling AAA accounting for the switch.
Switch(config)#aaa-accounting enable
52.3 aaa-accounting update
Command:
aaa-accounting update {enable | disable}
Function:
Enable or disable the AAA update accounting function.
Command Mode:
Global Mode.
Default:
Enable the AAA update accounting function.
Usage Guide:
After the update accounting function is enabled, the switch will sending accounting message to
each online user on time.
Example:
Disable the AAA update accounting function for switch.
Switch(config)#aaa-accounting update disable
52.4 debug aaa packet
Command:
debug aaa packet {send | receive | all} interface {ethernet <interface-number> |
<interface-name>}
no debug aaa packet {send | receive | all} interface {ethernet <interface-number> |
<interface-name>}
Function:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
