SGS-6341 Series Command Guide
5-142
another port isolation group, they will remain isolated from the ports in that group. If an Ethernet port is a member of
a convergence group, it should not be added into a port isolation group, and vice versa, a member of a port isolation
group should not be added into an aggregation group. But one port can be a member of one or more port isolation
groups.
Parameters:
<WORD> is the name identification of the group, no longer than 32 characters. If there is no such group with the
specified name, create one; ethernet means that the ports to be isolated is Ethernet ones, followed by a list of
Ethernet ports, supporting symbols like ”;” and ”-”. For example: “ethernet 1/1;3;4-7;8” <IFNAME> is the name of the
interface, such as e1/0/1. If users use interface name, the parameter of ethernet will not be required.
Command Mode:
Global Mode.
Usage Guide:
Users can add Ethernet ports into or remove them from a port isolation group according to their requirements. When
an Ethernet port is a member of more than one port isolate group, it will be isolated from every port of all groups it
belongs to.
Example:
Add Ethernet ports 1/0/1-2 and 1/0/5 into a port isolation group named as ”test”.
Switch(config)#isolate-port group test switchport interface ethernet 1/0/1-2; 1/0/5
5.3 isolate-port apply
Command:
isolate-port apply [<l2|l3|all>]
Function:
This command will apply the port isolation configuration to isolate layer-2 flows, layer-3 flows or all flows.
Parameters:
<l2|l3|all> the flow to be isolated, l2 means isolating layer-2 flows, l3 means isolating layer-3 flows, all means
isolating all flows.
Command Mode:
Global Mode.
Default:
Isolate all flows.
Usage Guide:
User can apply the port isolation configuration to isolate layer-2 flows, layer-3 flows or all flows according to their
requirements.
Example:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
