Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
3-122
SN Mac Description Hostname
--- ----------------- ------------------------ ------------------------
xxx xx-xx-xx-xx-xx-xx xxxxxxxxxxxxxxxxxxxxxx24 xxxxxxxxxxxxxxxxxxxxxx24
1 00-01-02-03-04-06 SGS-6341-24T4X
2 01-01-02-03-04-05 SGS-6341-24T4X MIS_zebra
3.17 show cluster topology
Command:
show cluster topology [root-sn <starting-node-sn> | nodes-sn <node-sn-list> | mac-address <mac-addr>]
Function:
Display cluster topology information. This command only applies to commander switches.
Parameters:
starting-node-sn：the starting node of the topology.
node-sn-list：the switch node sn.
mac-addr：the CPU mac address of the switch.
No parameters means to display all topology information.
Command Mode:
Admin and Configuration Mode.
Usage Guide:
Executing this command on the commander switch will display the topology information with its starting node
specified.
Example:
Execute this command on the commander switch to display the topology information under different conditions.
Switch#show cluster topology
Role: commander(CM);Member(M);Candidate(CA);Other commander(OC);Other member(OM)
LV SN Description Hostname Role MAC_ADDRESS Upstream Upstream leaf
local-port remote-port node
== ============ ============ == ================= ============ ============ =
x xxx xxxxxxxxxx12 xxxxxxxxxx12 xx xx-xx-xx-xx-xx-xx xxxxxxxxxx12 xxxxxxxxxx12 x
1 1 SGS-6341-24T4X LAB_SWITCH_1 CM 01-02-03-04-05-01 -root- -root- -
2 SGS-6341-24T4X LAB_SWITCH_2 M 01-02-03-04-05-
02 eth 1/1 eth 1/2 N
3 SGS-6341-24T4X LAB_SWITCH_3 CA 01-02-03-04-05-
03 eth 1/1 eth 1/3 Y
4 SGS-6341-24T4X LAB_SWITCH_4 CA 01-02-03-04-05-
04 eth 1/1 eth 1/4 Y
................................................................................
2 2 SGS-6341-24T4X LAB_SWITCH_2 M 01-02-03-04-05-02 eth 1/1 eth 1/2 -
5 SGS-6341-24T4X LAB_SWITCH_1 OC 01-02-03-04-05-13 eth 1/1 eth 1/2 Y

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
