Planet SGS-6341-24T4X User Manual

9-16
Command mode:
Port Mode
Default:
Long.
Usage Guide:
Set the timeout mode of LACP protocol.
Example:
Set the timeout mode as short in LACP protocol.
Switch(Config-If-Ethernet1/0/1)#lacp timeout short
9.6 load-balance
Command:
load-balance {dst-src-mac | dst-src-ip | dst-src-mac-ip}
Function:
Set load-balance mode for switch, it takes effect for port-group and ECMP at the same time.
Parameter:
dst-src-mac performs load-balance according to the source and destination MAC
dst-src-ip performs load-balance according to the destination and source IP
dst-src-mac-ip performs load-balance according to the destination and source MAC, the destination
and source IP
Command mode:
Global mode.
Default:
Perform load-balance according to the source and destination MAC.
Usage Guide:
Use port-channel or ECMP to implement load-balance, user can configure the load-balance mode
according to the requirements. If the specific load-balance mode of the command line is different
with the current load-balance mode, then modify the load-balance as the specific load-balance of
command line; otherwise return a message to notice that the current mode is already configured.
Example:
Set load-balance mode.
Switch(config)# load-balance src-mac-ip

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
