Planet SGS-6341-24T4X User Manual

19-184
19.2.20 ipv6 nd max-ra-interval
Command:
ipv6 nd max-ra-interval <seconds>
no ipv6 nd max-ra-interval
Function:
Set the maximum time interval of sending routing message.
Parameter:
Parameter <seconds> is number of seconds of the time interval of sending routing announcement,
<seconds> must be between 4-1800 seconds.
Command Mode:
Interface Configuration Mode
Default:
The default maximum time interval of sending routing announcement is 600 seconds.
Usage Guide:
The maximum time interval of routing announcement should be smaller than the lifetime value
routing announcement.
Example:
Set the maximum time interval of sending routing announcement is 20 seconds.
Switch(Config-if-Vlan1)#ipv6 nd max-ra-interval 20
19.2.21 ipv6 nd prefix
Command:
ipv6 nd prefix <ipv6-prefix | prefix-length> { [<valid-lifetime> <preferred-lifetime>]
[ no-autoconfig | off-link[no-autoconfig] ]}
no ipv6 nd prefix <ipv6-prefix | prefix-length>
Function:
Configure the address prefix and relative parameters for router announcement.
Parameter:
Parameter <ipv6-prefix> is the address prefix of the specified announcement, parameter
<prefix-length> is the length of the address prefix of the specified announcement, parameter
<valid-lifetime> is the valid lifetime of the prefix, parameter <preferred-lifetime> is the preferred
lifetime of the prefix, and the valid lifetime must be no smaller than preferred lifetime. Parameter
no-autoconfig says this prefix can not be used to automatically configure IPv6 address on the host
in link-local. Parameter off-link says the prefix specified by router announcement message is not
assigned to link-local, the node which sends data to the address including this prefix consider

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
