Planet SGS-6341-24T4X User Manual

13-87
<aging-time> is the aging-time seconds, range from 10 to 1000000; 0 to disable aging.
Command Mode:
Global Mode.
Default:
Default aging-time is 300 seconds.
Usage Guide:
If no destination address of the packets is same with the address entry in aging-time, the address
entry will get aged. The user had better set the aging-time according to the network condition, it
usually use the default value.
Example:
Set the aging-time to 600 seconds.
Switch(config)#mac-address-table aging-time 600
13.1.3 mac-address-table static | static-multicast |
blackhole
Command:
mac-address-table {static | static-multicast | blackhole} address <mac-addr> vlan <vlan-id>
[interface [ethernet | portchannel] <interface-name>] | [source | destination | both]
no mac-address-table {static | static-multicast | blackhole | dynamic} [address <mac-addr>]
[vlan <vlan-id>] [interface [ethernet | portchannel] <interface-name>]
Function:
Add or modify static address entries, static multicast entries and filter address entries. The no
command deletes the three entries.
Parameter:
static is the static entries; static-multicast is the static multicast entries; blackhole is filter entries,
which is for discarding frames from specific MAC address, it can filter source address, destination
address or the both. When choose the filter entries, blackhole address can’t based on port, and not
configure to interface; dynamic is dynamic address entries; <mac-addr> MAC address to be added
or deleted; <interface-name> name of the port transmitting the MAC data packet; <vlan-id> is the
vlan number. source is based on source address filter; destination is based on destination address
filter; both is based on source address and destination address filter, the default is both.
Command Mode:
Admin and Configuration Mode.
Default:

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
