Planet SGS-6341-24T4X User Manual

12-75
dynamic VLAN is available. This command is used to set to preferring the IP-subnet-based VLAN.
Example:
Set the IP-subnet-based VLAN preferred.
Switch#config
Switch(config)#dynamic-vlan subnet-vlan prefer
12.2.3 mac-vlan
Command:
mac-vlan mac <mac-addrss> vlan <vlan-id> priority <priority-id>
no mac-vlan {mac <mac-addrss>|all}
Function:
Add the correspondence between MAC address and VLAN, namely specify certain MAC address to
join specified VLAN. The “no” form of this command deletes all/the correspondence.
Parameter:
mac-address is the MAC address which is shown in the form of XX-XX-XX-XX-XX-XX,vlan-id is the
ID of the VLAN with a valid range of 1~4094;priority-id is the level of priority and is used in the VLAN
tag with a valid range of 0~7;all refers to all the MAC addresses.
Command Mode:
Global Mode.
Default:
No MAC address joins the VLAN by default.
Usage Guide:
With this command user can add specified MAC address to specified VLAN. If there is a non VLAN
label data packet enters from the switch port from the specified MAC address, it will be assigned
with specified VLAN ID so sent enter specified VLAN. Their belonging VLAN are the same no
matter which port did they enter through. The command does not have any interfere on the VLAN
label data packet.
Example:
Add network device of MAC address as 00-30-4f-11-22-33 to VLAN 100.
Switch#config
Switch(config)#mac-vlan mac 00-30-4f-11-22-33 vlan 100 priority 0

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
