Planet SGS-6341-24T4X User Manual

13-96
Usage Guide:
The MAC address binding function must be enabled before maximum secure MAC address number
can be set. If secure static MAC address number of the port is larger than the maximum secure
MAC address number set, the setting fails; extra secure static MAC addresses must be deleted, so
that the secure static MAC address number is no larger than the maximum secure MAC address
number for the setting to be successful.
Example:
Set the maximum secure MAC address number for port 1.
Switch(config)#interface Ethernet 1/0/1
Switch(Config-If-Ethernet1/0/1)# switchport port-security maximum 4
13.2.11 switchport port-security timeout
Command:
switchport port-security timeout <value>
no switchport port-security timeout
Function:
Set the timer for port locking; the “no switchport port-security timeout” command restores the
default setting.
Parameter:
< value> is the timeout value, the valid range is 0 to 300s.
Command mode:
Port Mode.
Default:
Port locking timer is not enabled by default.
Usage Guide:
The port locking timer function is a dynamic MAC address locking function. MAC address locking
and conversion of dynamic MAC entries to secure address entries will be performed on locking
timer timeout. The MAC address binding function must be enabled prior to running this command.
Example:
Set port1 locking timer to 30 seconds.
Switch(config)#interface Ethernet 1/0/1
Switch(Config-If-Ethernet1/0/1)# switchport port-security timeout 30

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
