31-124
route do not announce outside the local AS (but can announce among the sub AS within the
confederation), [no-advertise] means this route do not send to any neighbor, [no-export] means
this route do not send to EBGP neighbors, [none] means delete the community attributes from the
prefix of this route, [additive] means add following existing community attributes.
Command Mode:
route-map mode
Usage Guide:
To use this command, one match clause should at first be defined.
Example:
Switch#config terminal
Switch(config)#route-map r1 permit 5
Switch(config-route-map)#set community local-as additive
31.20 set extcommunity
Command:
set extcommunity <rt | soo> <AA:NN>
no set extcommunity <rt | soo> [<AA:NN>]
Function:
Configure the extended community attributes of the BGP routing message. The no set
extcommunity <rt | soo> [<AA:NN>]” command deletes this configuration.
Parameter:
<rt> is the route target, <soo> is the site of origin, <AA:NN> is the value of community attributes,
amongst AA is AS number, ranging from 1 to 4294967295, it can be shown in decimal notation
(such as 6553700) or delimiter method (such as 100.100), NN is a random two byte number.
Command Mode:
route-map mode
Usage Guide:
To use this command, one match clause should at first be defined.
Example:
Set rt as 100:10
Switch#config terminal
Switch(config)#route-map r1 permit 5
Switch(config-route-map)#set extcommunity rt 100:10
Set soo as 200.200:10
