Planet SGS-6341-24T4X User Manual

12-77
ssap-id is the access point of the source service with a valid range of 0~255;
snap is SNAP encapsulate format;
etype-id is the type of the packet protocol, the valid range is 1536~65535;
vlan-id is the ID of VLAN, the valid range is 1~4094;
priority is the priority, the range is 0~7;
all indicates all the encapsulate protocols.
Command Mode:
Global Mode.
Default:
No protocol joined the VLAN by default.
Usage Guide:
The command adds specified protocol into specified VLAN. If there is any non VLAN label packet
from specified protocol enters through the switch port, it will be assigned with specified VLAN ID
and enter the specified VLAN. No matter which port the packets go through, their belonging VLAN is
the same. The command will not interfere with VLAN labeled data packets. It is recommended to
configure ARP protocol together with the IP protocol or else some application may be affected.
Example:
Assign the IP protocol data packet encapsulated by the EthernetII to VLAN200.
Switch#config
Switch(config)#protocol-vlan mode ethernetii etype 2048 vlan 200
12.2.6 show dynamic-vlan prefer
Command:
show dynamic-vlan prefer
Function:
Display the preference of the dynamic VLAN.
Command Mode:
Admin Mode and Configuration Mode.
Usage Guide:
Display the dynamic VLAN preference.
Example:
Display current dynamic VLAN preference.
Switch#show dynamic-vlan prefer
Mac Vlan/Voice Vlan
IP Subnet Vlan
Protocol Vlan

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
