Planet SGS-6341-24T4X User Manual

12-80
------------------ ----------------- -------
192.168.1.165 255.255.255.0 2
202.200.121.21 255.255.0.0 2
10.0.0.1 255.248.0.0 5
12.2.11 show subnet-vlan interface
Command:
show subnet-vlan interface
Function:
Display the port at IP-subnet-based VLAN.
Command Mode:
Admin Mode and other Configuration Mode.
Usage Guide:
Display the port of enabling IP-subnet-based VLAN, the character in the bracket indicate the ports
mode, A means Access port, T means Trunk port, H means Hybrid port.
Example:
Display the port of enabling IP-subnet-based VLAN currently.
SwitchA#show subnet-vlan interface
Ethernet1/0/1(A) Ethernet1/0/2(A)
Ethernet1/0/3(A) Ethernet1/0/4(A)
Ethernet1/0/5(H) Ethernet1/0/6(T)
12.2.12 subnet-vlan
Command:
subnet-vlan ip-address <ipv4-addrss> mask <subnet-mask> vlan <vlan-id> priority
<priority-id>
no subnet-vlan {ip-address <ipv4-addrss> mask <subnet-mask> | all}
Function:
Add a correspondence between the IP subnet and the VLAN, namely add specified IP subnet into
specified VLAN; the “no" form of this command deletes all/the correspondence.
Parameter:
ipv4-address is the IPv4 address shown in dotted decimal notation; the valid range of each section
is 0~255; subnet-mask is the subnet mask code shown in dotted decimal notation; the valid range of
each section is 0~255; priority-id is the priority applied in the VLAN tag with a valid range of 0~7;

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
