Page #52 background imageLoading...
Page #52 background image
SGS-6341 Series Command Guide
1-52
1.1.5 clock set
Command:
clock set <HH:MM:SS> <YYYY.MM.DD>
Function:
Set system date and time.
Parameter:
<HH:MM:SS>is the current time, and the valid scope for HH is 0 to 23, MM and SS 0 to 59; <YYYY.MM.DD> is the
current year, month and date, and the valid scope for YYYY is 1970~2038, MON meaning month, and DD between 1
to 31.
Command mode:
Admin Mode.
Default:
upon first time start-up, it is defaulted to 2006.1.1 0: 0: 0.
Usage guide:
The switch can not continue timing with power off, hence the current date and time must be first set at environments
where exact time is required.
Example:
To set the switch current date and time to 2002.8.1 23: 0: 0:
Switch#clock set 23:0:0 2002.8.1
Relative Command:
show clock
1.1.6 config
Command:
config [terminal]
Function:
Enter Global Mode from Admin Mode.
Parameter:
[terminal] indicates terminal configuration.
Command mode:
Admin Mode
Example:
Switch#config
