Page #98 background imageLoading...
Page #98 background image
SGS-6341 Series Command Guide
1-98
Relevant Command:
Write
1.5.2 copy
TFTP
Command:
copy <source-url> <destination-url> [ascii | binary]
Function:
Download files to the TFTP client.
Parameter:
<source-url> is the location of the source files or directories to be copied;
<destination-url> is the destination address to which the files or directories to be copied; forms of <source-url> and
<destination-url> vary depending on different locations of the files or directories.
ascii indicates the ASCII standard will be adopted;
binary indicates that the binary system will be adopted in the file transmissiondefault transmission method.When
URL represents an TFTP address, its form should be: tftp://{<ipaddress>|<ipv6address>|<hostname>}/<filename>,
amongst <ipaddress>| <ipv6address> is the IPv4 or IPv6 address of the TFTP server/client, <hostname> is the
name of the host mapping with the IPv6 address, it does not support the file download and upload with hosts
mapping with IPv4 addresses,<filename> is the name of the TFTP upload/download file.
Special keyword of the filename
Keywords
Source or destination addresses
running-config
Running configuration files
startup-config
Startup configuration files
nos.img
System files
nos.rom
System startup files
Command Mode:
Admin Mode.
Usage Guide:
This command supports command line hints, namely if the user can enter commands in following forms: copy
<filename> tftp:// or copy tftp:// <filename> and press Enter, following hints will be provided by the system:
tftp server ip/ipv6 address[x.x.x.x]/[x:x::x:x]>
tftp filename>
Requesting for TFTP server address, file name
Example:
(1) Save images in the FLASH to the TFTP server of 10.1.1.1
Switch#copy nos.img tftp://10.1.1.1/nos.img
(2) Obtain system file nos.img from the TFTP server 10.1.1.1
