Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
4-132
Parameters:
interrupt: the interrupt mode; poll: the poll mode.
Command mode:
Global Mode.
Default:
Poll mode.
Usage Guide:
There are two modes that can respond up/down event of the port. The interrupt mode means that interrupt hardware
to announce the up/down change, the poll mode means that software poll can obtain the port event, the first mode is
rapid. If using poll mode, the convergence time of MRPP is several hundred milliseconds, if using interrupt mode, the
convergence time is less than 50 milliseconds.
Notice: The scan mode of the port usually configured as poll mode, the interrupt mode is only used to the
environment of the good performance, but the security of the poll mode is better.
Example:
Configure the scan mode of the port as interrupt mode.
Switch(config)# port-scan-mode interrupt
4.1.12 rate-suppression
Command:
rate-suppression {dlf | broadcast | multicast} <packets>
no rate-suppression {dlf | broadcast | multicast}
Function:
Sets the traffic limit for broadcasts, multicasts and unknown destination unicasts on all ports in the switch; the no
command disables this traffic throttle function on all ports in the switch, i.e., enables broadcasts, multicasts and
unknown destination unicasts to pass through the switch at line speed.
Parameters:
use dlf to limit unicast traffic for unknown destination; multicast to limit multicast traffic; broadcast to limit broadcast
traffic. <packets> is the limit of packet number, ranging from 1 to 1488905. For non-10GB ports, the unit of <packets>
is PPS, that is, the value of <packets> is the number of packets allowed to pass per second; for 10GB ports, the unit
is KPPS, that is, the value of <packets> multiplies 1000 makes the number of packets allowed, so the value should
be less than 14880.
Command mode:
Port Mode.
Default:
No limit is set by default. So, broadcasts, multicasts and unknown destination unicasts are allowed to pass at line
speed.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
