Planet SGS-6341-24T4X User Manual

32-136
32.3 show ip route
Command:
show ip route [<destination>|<destination >|<length>|connected | static | rip| ospf | bgp | isis|
kernel| statistics| database [connected | static | rip| ospf | bgp | isis| kernel] |fib[statistics]]
Function:
Show the route table.
Parameter:
<destination> is the destination network address; <destination >/<length> is the destination
network address plus the length of prefix; connected is direct route; static is static route; rip is RIP
route; ospf is OSPF route; bgp is BGP route; isis is ISIS route; kernel is kernel route; statistics
shows the number of routes; database is route database; fib is kernel route table.
Command Mode:
Admin mode
Usage Guide:
Show all the contents in the route table including: route type, destination network, mask, next-hop
address, interface, etc
Example:
switch#show ip route
Codes: K - kernel, C - connected, S - static, R - RIP, B - BGP
O - OSPF, IA - OSPF inter area
N1 - OSPF NSSA external type 1, N2 - OSPF NSSA external type 2
E1 - OSPF external type 1, E2 - OSPF external type 2
i - IS-IS, L1 - IS-IS level-1, L2 - IS-IS level-2, ia - IS-IS inter area
* - candidate default
Gateway of last resort is 210.0.0.3 to network 0.0.0.0
S* 0.0.0.0/0 [1/0] via 210.0.0.3, Vlan1
C 127.0.0.0/8 is directly connected, Loopback
O IA 172.16.11.0/24 [110/40] via 210.14.0.1, Vlan3014, 00:00:47
O IA 172.16.12.0/24 [110/40] via 210.14.0.1, Vlan3014, 00:00:47
O IA 172.16.13.0/24 [110/40] via 210.14.0.1, Vlan3014, 00:00:47
O IA 172.16.14.0/24 [110/40] via 210.14.0.1, Vlan3014, 00:00:47
O IA 172.16.15.0/24 [110/50] via 210.14.0.1, Vlan3014, 00:00:47
O E2 172.16.100.0/24 [110/0] via 210.14.0.1, Vlan3014, 00:00:46
Displayed information
Explanation
C –connected
Direct route, namely the segment directly

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
