Planet SGS-6341-24T4X User Manual

32-137
connected with the layer 3 switch
S –static Static route, the route manually co
nfigured by
users
R - RIP derived RIP route, acquired by layer 3 switch through the
RIP protocol.
O - OSPF derived OSPF route, acquired by layer 3 switch through the
OSPF protocol
A- OSPF ASE
Route introduced by OSPF
B- BGP derived
BGP route, acquired by the BGP protocol.
Destination
Target network
Mask
Target network mask
Nexthop
Next-hop IP address
Interface
Next-hop pass-by layer 3 swtich interfaces
Preference Route priority. If other types of route to the target
network exists, the kernel route will only shows
those with high priority.
32.4 show ip route vrf
Command:
show ip route vrf <name> [connected | static | rip| ospf | bgp | isis| kernel|statistics|
database[connected | static | rip| ospf | bgp | isis|kernel] ]
show ip route fib vrf <name> [default|main|local]
Function:
Show the routing tables entries.
Parameters:
<name> is the name of the forwarding instance of VPN route; <destination> is the destination
address; <destination>/<length> are the network address for the destination as well as the length
of the network mask; connected is for direct route; static is for static route; rip is for the RIP route
protocol; ospf is for the OSPF route protocol; bgp is for the BGP route protocol; isis is for the ISIS
route protocol; kernel is for the kernel route protocol; statistics are the number of route entries to
be displayed; database is for the route database; fib is for the core route table.
Command Mode:
all modes.
Usage Guide:
To display the contents of the VPN routing table, including routing type, destination network address,
address mask, the address and interface for the next hop, etc.

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
