Planet SGS-6341-24T4X User Manual

SGS-6341 Series Command Guide
4-125
Chapter 4 Commands for Network Port
Configuration
4.1 Commands for Ethernet Port Configuration
4.1.1 bandwidth
Command:
bandwidth control <bandwidth> {transmit | receive | both}
no bandwidth control
Function:
Enable the bandwidth limit function on the port; the no command disables this function.
Parameter:
<bandwidth> is the bandwidth limit, which is shown in Mbps ranging between 1-1000000K; both refers to the
bandwidth limit when the port receives and sends data, receive refers to the bandwidth limit will only performed when
the switch receives data from out side, while transmit refers to the function will be perform on sending only.
Command Mode:
Port Mode.
Default:
Bandwidth limit disabled by default.
Usage Guide:
When the bandwidth limit is enabled with a size set, the max bandwidth of the port is determined by this size other
than by 10/100/1000M. If [both | receive | transmit] keyword is not specified, the default is both.
The bandwidth limit can not exceed the physic maximum speed pos
sible on the port. For
example, an 10/100M Ethernet port can not be set to a bandwidth limit at 101000K
(or
higher), but applicable on a 10/100/1000 port working at a speed of 100M.
Example:
Set the bandwidth limit of 1/1-8 port is 40000K.
Switch(config)#interface ethernet 1/1-8
Switch(Config-If-Port-Range)#bandwidth control 40000 both

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
