Page #931 background imageLoading...
Page #931 background image
45-77
Global Mode
Default:
255s
Usage Guide:
This command can only be configured on L2 general querier. The Suppression-query-time
represents the period the suppression state maintains when general querier receives queries from
layer 3 MLD within the segment. To use this command, the query-intervals in different switches
within the same segment must be in accordance. It is recommended to use the default value.
Example:
Switch(config)#ipv6 mld snooping vlan 2 suppression-query-time 270
45.8.17 show ipv6 mld snooping
Command:
show ipv6 mld snooping [vlan <vlan-id>]
Parameter:
<vlan-id> is the number of VLAN specified to display the MLD Snooping messages
Command Mode:
Admin Mode
Usage Guide:
If no VLAN number is specified, it will show whether the global MLD snooping is enabled and layer 3
multicast protocol is running, as well as on which VLAN the MLD Snooping is enabled and
configured l2-general-querier. If a VLAN number is specified, the detailed MLD Snooping messages
of this VLAN will be displayed.
Example:
1. Summary of the switch MLD snooping
Switch(config)#show ipv6 mld snooping
Global mld snooping status: Enabled
L3 multicasting: running
Mld snooping is turned on for vlan 1(querier)
Mld snooping is turned on for vlan 2
--------------------------------
Displayed Information
Explanation
Global mld snooping status
Whether or not the global MLD Snooping is enabled on the switch
L3 multicasting
Whether or not the layer 3 multicast protocol is running on the
