Planet SGS-6341-24T4X User Manual

12-54
Note:This will remove all the ports from vlan 200
Switch(Config-Vlan200)#exit
Switch(config)#vlan 300
Switch(Config-Vlan300)#private-vlan community
Note:This will remove all the ports from vlan 300
Switch(Config-Vlan300)#exit
12.1.13 private-vlan association
Command:
private-vlan association <secondary-vlan-list>
no private-vlan association
Function:
Set Private VLAN association; the no command cancels Private VLAN association.
Parameter:
<secondary-vlan-list> Sets Secondary VLAN list which is associated to Primary VLAN. There are
two types of Secondary VLAN: Isolated VLAN and Community VLAN. Users can set multiple
Secondary VLANs by “;”.
Command mode:
VLAN Mode.
Default:
There is no Private VLAN association by default.
Usage Guide:
This command can only used for Private VLAN. The ports in Secondary VLANs which are
associated to Primary VLAN can communicate to the ports in Primary VLAN.
Before setting Private VLAN association, three types of Private VLANs should have no member
ports; the Private VLAN with Private VLAN association can’t be deleted. When users delete Private
VLAN association, all the member ports in the Private VLANs whose association is deleted are
removed from the Private VLANs.
Example:
Associate Isolated VLAN200 and Community VLAN300 to Primary VLAN100.
Switch(Config-Vlan100)#private-vlan association 200;300

Planet SGS-6341-24T4X Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Form factor	1U
Certification	FCC Part 15 Class A, CE
Product color	Black
Console port	RJ-45
SFP+ module slots quantity	4
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Routing entries	128
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T
Flash memory	16 MB
Internal memory	512 MB
Processor frequency	400 MHz
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	SNMPv3, SSH, SSL/TLS
Throughput	95.24 Mpps
Jumbo frames	9216
Number of queues	8
MAC address table	16000 entries
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply included	-
Power consumption (max)	19.9 W
Heat dissipation	67.91 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	240 mm
Width	440 mm
Height	43.6 mm
Weight	3170 g
