Page #1201 background imageLoading...
Page #1201 background image
78-16
Setting a global max output power can guarantee a secure power supply and an effective method
to control the power consumed by connected subordinate devices.
Example:
Set the global max output power to 50W.
Switch(Config)#power inline max 50
78.1.6 power inline max (Port)
Command:
power inline max <max-wattage>
no power inline max
Function:
Set the max output power of a specified port.
Parameters:
max-wattage: the value of the max output power, in mW, ranging from 1 to 15400mW (802.3af)/1 to
3000mW (802.3at), with a granularity of 100mW. Any value less than 100mW will be taken as
100mW, that is, 1~100 equals 100, 15301~15400 equals 15400. But the value set by users will be
maintained without being rounded up.
Command Mode:
Port Mode.
Default:
The max output power of a port is 15400mW (802.3af)/3000mW (802.3at).
Usage Guide:
This configuration will effectively control the output power of each port in cooperation with the global
max power.
Example:
Set the max output power of Port 1 to 0.8W.
Switch(Config)#interface ethernet 1/0/1
Switch(Config-Ethernet1/0/1)#power inline max 800
78.1.7 power inline police
Command:
power inline police enable
no power inline police enable
Function:
Enable/disable the power priority management policy mode.
Parameters:
